Ballistic Seperator

Get a Price/Quote

Ballistic Seperator Specification

Type
Ballistic Separator

Material
Stainless Steel / MS

Operating Type
Automatic

Usage Level
Industrial

Portable
No

Recyclable
Yes

Noise Level
Low

Power Source
Electric

Power Consumption
12-18 kW

Dimension (L*W*H)
5200 x 2250 x 2700 mm

Weight (kg)
2700 - 3500

Color
Green/Grey

Capacity
12-20 TPH

Fraction Output
3 (2D, 3D, Fines)

Control Panel
PLC Controlled

Separation Efficiency
90-95%

Application
Municipal Solid Waste, MRF, Recycling Plants

Operating Voltage
415 V, 50 Hz

Frame Construction
Heavy Duty Steel Frame

Maintenance
Low Maintenance Design

Surface Treatment
Powder Coated

Safety Features
Emergency Stop, Overload Protection

Drive Motor
15 HP 3 Phase

Working Temperature
-10C to +50C

Screen Width
1200 mm

Screen Length
4200 mm

Feeding Method
Belt Conveyor

Humidity Tolerance
Up to 95% RH

About Ballistic Seperator

Ballistic Separator / Solid Waste Ballistic Separator

Product Description

GenX SynerTech manufactures advanced Ballistic Separators designed for efficient segregation of municipal solid waste, recyclable materials, mixed dry waste, and industrial waste streams. The systems are engineered for high-capacity waste processing plants and material recovery facilities requiring automatic separation of light, heavy, rolling, and flat waste materials.

The separator improves recycling efficiency by accurately separating waste into different fractions for downstream processing and resource recovery operations.

Technical Specifications

Parameter	Details
Machine Type	Automatic Waste Separator
Application	Solid Waste Segregation
Structure Material	Heavy Duty MS Fabrication
Processing Capacity	Customizable
Drive Type	Electric Motor Driven
Operation Type	Continuous Duty
Screening Mechanism	Oscillating Ballistic Motion
Waste Type	Dry Municipal Waste
Separation Output	2D / 3D / Fine Fraction
Control System	PLC Optional
Installation Type	Fixed Plant Installation
Power Requirement	As Per Capacity
Maintenance Type	Low Maintenance
